Rollsign Gallery - Electronic Sign Gallery

90 pixel width
7 pixel height

(3 panels of
7 x 30)

1989

Luminator GTI: MAX - Front (7 x 90)

90 pixel width
7 pixel height

(3 panels of
7 x 30)

1989

Luminator GTI: MAX - Side (7 x 90)

14 x 28 pixels
(route number)

7 x 75 pixels
(route name)
2 panels of
7 x 30, one
panel of 7 x 15

1990

Luminator GTI: MAX Split Sign - Front

Route
name sign

12V / 10 Amp
(12V or 24V for tube
lights depending on
the ballasts inside)

112 pixel width
16 pixel height

(4 panels of
16 x 28)

1989

Luminator GTI: MegaMAX - Front

112 pixel width
16 pixel height

(4 panels of
16 x 28)

1992

Luminator GTI: "Mini" MegaMAX - Front

24 Volt
10 Amp

112 pixel width
16 pixel height

(4 panels of
16 x 28)

1999

GTI-Luminator "Mini" MegaMAX: 3000 - Front

24 Volt
10 Amp

90 pixel width
7 pixel height

(3 panels of
7 x 30)

1999

GTI-Luminator MAX: 3000 - Side

24 Volt
10 Amp

23 pixel width
10 pixel height

(1 panel)

1998

GTI-Luminator MAX: 3000 - Rear (Version 1)

24 Volt
10 Amp

160 pixel width
16 pixel height

(4 panels of
16 x 40)

2001

Luminator Horizon - Front 16x160

N / A

24 Volt
10 Amp

96 pixel width
8 pixel height

(2 panels of
8 x 48)

2001

Luminator Horizon - Side

N / A

Electronic Sign Gallery
Luminator (A Mark IV Industries Co.) / Luminator Technology Group

Number
sign

23 pixel width
7 pixel height

(1 panel)

1989

Luminator GTI: MAX - Rear (7 x 23)

23 pixel width
7 pixel height

(1 panel)

1997

Luminator MAX: 2000 - Rear (7 x 23)

Luminator ODK-1 (English) with dial
adjustment for the display dimmer.

1990

Luminator ODK-1 (French)

1990

Luminator ODK-2, Standard facing

1992

Luminator ODK-3

1998

Luminator ODK-3+ (3 Plus)

2008

Luminator ODK-2 with the Passenger Info. &
Next Stop Announcement System facing

1992

24 Volt
10 Amp

120 pixel width
16 pixel height

(3 panels of
16 x 40)

2001

Luminator Horizon - Front 16x120

N / A

24 Volt
10 Amp

48 pixel width
16 pixel height

(1 panel)

2001

Luminator Horizon - Side Route Number

N / A

24 Volt
10 Amp

40 pixel width
12 pixel height

(1 panel)

2001

Luminator Horizon - Dash (Front window)

N / A

24 Volt
10 Amp

23 pixel width
10 pixel height

(1 panel)

1999

GTI-Luminator MAX: 3000 - Rear (Version 2)

NOTE: The outer facing and driver electronics are different than the Version 1 rear sign.

NOTE: The outer facing and driver electronics are different than the Version 2 rear sign.

24 Volt
10 Amp

23 pixel width
10 pixel height

(1 panel)

1999

GTI-Luminator MAX: 3000 - Rear (Basic Frame)

24 Volt
10 Amp

30 pixel width
7 pixel height

(1 panel)

1999

GTI-Luminator MAX: 3000 - Dash (Front Window)

24 Volt
10 Amp

30 pixel width
10 pixel height

(1 panel)

1999

GTI-Luminator MAX: 3000 - Side Route Number

NOTE: The outer facing and the interior driver electronics are the same on this unit as
the Luminator MAX3000 ~VERSION 1~ rear sign seen below, except for the light ballast.

75 pixel width
7 pixel height

(2 panels of
7 x 30 and one
panel of 7 x 15)

1989

Luminator GTI: MAX - Front (7 x 75)

75 pixel width
7 pixel height

(2 panels of
7 x 30 and
one panel
of 7 x 15)

1989

Luminator GTI: MAX - Side (7 x 75)

Luminator ODK-1 (English)

1990

12V / 24V
10 Amp
(minimum)

5 pixel width
7 pixel height
per character;

16 character
display
(4 panels of 4)

1991

Luminator LCD: MAX (Liquid Crystal Display) - Side

N / A

Each LCD dot is 7/32" wide by 1/4" high. Each character on the display is 1 1/4" wide by 2" high.
NOTE: For some reason, these signs DO NOT work when paired with an ODK4 touch screen keypad.

Luminator ODK-4

2014
